型號：Q0069-00
|
ZEN: 1.01.0135.0 | WAI: 54-208 | Lester: 3208 OEM NO: 1843041, C8FF11350A, 1838065, 1916775 |
||
| No Of Teeth:9 | Rotation:CW | Length (mm):77 |
| Pinion O.D. (mm):25.7 | No Of Splines:4 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):48.6 | ||
型號：Y0042-00
|
ZEN: 1.01.0729.0 | WAI: 54-9171 | Lester: 17223 OEM NO: 1006209579, 1006209917, 9001081010, TNB010 |
||
| No Of Teeth:10 | Rotation:CCW | Length (mm):77 |
| Pinion O.D. (mm):28 | No Of Splines:10 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):48 | ||
型號：Q0040-00
|
ZEN: 1.01.0499.0 | WAI: 54-8101 | Lester: 16774/16674 OEM NO: S114-320A, 211445504, 23312D0100, S114-320 |
||
| No Of Teeth:8 | Rotation:CW | Length (mm):60 |
| Pinion O.D. (mm):28.2 | No Of Splines:5 | Pinion I.D. (mm):12.5 |
| Drive O.D. (mm):48 | ||
型號：Y0037-00
|
ZEN: 1.01.0249.0 | WAI: 54-9401 | Lester: 16751 OEM NO: 181804 |
||
| No Of Teeth:9 | Rotation:CW | Length (mm):55.5 |
| Pinion O.D. (mm):25.7 | No Of Splines:9 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):48 | ||
型號：Y0026-00
|
ZEN: 1.01.0787.0 | WAI: 54-9434 | Lester: 17667 OEM NO: 186938, 188887, 21020761, 21020892 |
||
| No Of Teeth:9 | Rotation:CW | Length (mm):51.5 |
| Pinion O.D. (mm):25.7 | No Of Splines:5 | Pinion I.D. (mm):12 |
| Drive O.D. (mm):48 | ||
型號：J0160-00
|
ZEN: | WAI: 54-8406 | Lester: OEM NO: 6582, 6498, 10456455, 10457121 |
||
| No Of Teeth:10 | Rotation:CW | Length (mm):67 |
| Pinion O.D. (mm):32.1 | No Of Splines:12 | Pinion I.D. (mm):14 |
| Drive O.D. (mm):67 | ||
